Hoja de Datos
|
Fabricante
|
Nichicon
|
|
|
Serie
|
UPJ
|
|
|
|
|
Part Status
|
Active
|
|
|
Capacitance
|
820 µF
|
|
|
Tolerance
|
±20%
|
|
|
Voltage – Rated
|
6.3 V
|
|
|
ESR (Equivalent Series Resistance)
|
–
|
|
|
Lifetime @ Temp.
|
3000 Hrs @ 105°C
|
|
|
Operating Temperature
|
-55°C ~ 105°C
|
|
|
Polarization
|
Polar
|
|
|
Ratings
|
–
|
|
|
Applications
|
General Purpose
|
|
|
Ripple Current @ Low Frequency
|
670 mA @ 120 Hz
|
|
|
Ripple Current @ High Frequency
|
795 mA @ 10 kHz
|
|
|
Impedance
|
130 mOhms
|
|
|
Lead Spacing
|
0.138″ (3.50mm)
|
|
|
Size / Dimension
|
0.315″ Dia (8.00mm)
|
|
|
Height – Seated (Max)
|
0.827″ (21.00mm)
|
|
|
Surface Mount Land Size
|
–
|
|
|
Mounting Type
|
Through Hole
|
|
|
Package / Case
|
Radial, Can
|
